Motorola P3688

Suitable for industry

[product_industries]
  • The Motorola XiR P3688 is a rugged analog and digital portable radio designed for efficient workforce coordination. It delivers superior audio with digital noise cancellation and operates up to 40% longer than analog models on the same battery. Built to IP54 durability standards, it uses Dual Capacity Direct Mode to double channel capacity without the need for extra infrastructure.
WHATSAPP TO GET QUOTE
DOWNLOAD BROCHURE

DESCRIPTION

General

  • Frequency Range

    403-470 MHz (UHF)

  • Channel Capacity

    32

  • Channel Spacing

    12.5kHz , 20kHz , 25kHz

  • Operating Voltage

    7.5V DC

  • Dimensions (H-W-D) [with Standard Battery]

    127.7mm x 61.5mm x 44.0mm

  • Weight with Standard Battery

    346g

  • Standard Battery Capacity

    2250mAh

  • Battery Life

    Analog: 14.5 Hours
    Digital: 18.5 Hours

RF Specification

  • RF Power Output

    1W / 4W

  • Sensitivity

    Analog - 0.22 μV
    Digital - 0.19 μV

Environmental

  • Operating Temperature

    -30 °C to 60 °C

  • Storage Temperature

    -40 °C to 85 °C

  • Dust & Water Protection

    IEC60529 - IP54

  • Electrostatic Discharge

    IEC61000-4-2 Level 3

  • Packaging Test

    MIL-STD 810 D and E
