General
-
Frequency Range
VHF: 136-174Mhz
-
Channel Capacity
256
-
Zone Capacity
16
-
Channel Spacing
12.5kHz / 20kHz / 25kHz
-
Operating Voltage
7.4V DC±20%
-
Battery
2000mAh Li-ion (standard)
-
Battery Life [5-5-90 Duty Circle, High TX Power]
Analog: 15 hours @ 2000mAh
Digital: 18 hours @ 2000mAh
-
Dimensions (H-W-D) [with standard battery, without antenna]
116 x 54 x 31mm
-
Weight [with standard battery]
About 280g
-
RF Power Output
VHF: 1W/5W; UHF: 1W/4W
-
Sensitivity
Analog: 0.22μV (12dB SINAD)
Digital: 0.22μV/BER5% -
Operating Temperature
-30℃ ~ +60℃
-
Storage Temperature
-40℃ ~ +85℃
Environmental
-
Operating Temperature
-20℃ to 60℃
-
Storage Temperature
-40℃ to 85℃
-
Dust & Water Protection
IP54
